360 EXPRESS
8–38
Hardtop Accessories Layout
The hardtop harness routes through the
hardtop frame into the rigging area behind
the helm table where it connects to the aft
hull harness. The main 12V DC positive and
negative wiring for the hardtop route
to the DC positive and DC negative bus
bars located behind the AC/DC panel.
Hardtop DC
Negative Bus
(Accessed through
4" access plate)
Dual Trumpet Horn
6" Water Resistant
Stereo Speakers
Dome Light with
white & red bulbs
Mast Light
Spreader Lights
To Next Page
