Grady-White 360 express - Volt DC Fuse Block Diagram

360 EXPRESS
8–46
12 Volt DC Fuse Block Diagram
LINE
NO.
1.
MAIN ACC. DC NEG. BUS
6 GA R
12 GANG FUSE BLOCK POS. BUS
ATO
15A
FU
ACCESSORY
OUTLET #1
10 GA R/ORG
10 GA BLK
10 GA BLK
10 GA R/ORG
ACCESSORY
OUTLET #2
FU
15A
ATO
ATO
15A
FU
ACCESSORY
OUTLET #3
10 GA R/ORG
10 GA BLK
16 GA BLK
16 GA BRN/GN
HEAD VENT
FU
3A
ATO
ATO
20A
FU
TRIM TABS
(SEE DWG
360-DC-9)
14 GA ORG
14 GA BLK
SEE DWG
360-DC-1-1
LINE 9
ATO
15A
FU
WIPER CONTROL
PANEL W/
INTERNAL 10A
FUSE
(SEE DWG
360-DC-6)
14 GA ORG
14 GA BLK
2.
3.
4.
5.
6.
7.
8.
NOTES:
1) INDICATES MULTI-CONDUCTOR CABLE
SEE DWG
360-DC-6
LINES 1, 3, 4, & 5
8C 16 GA
9. 16 GA BLU/GRY
FU
5A
ATO
SEE DWG
360-DC-8 LINE 7
MAIN ACC. DC NEG. BUS
HEAD VENT
SW. IN HEAD
(AFT NEAR BATTERIES) (AFT NEAR BATTERIES)
6 GA BLK12 GANG FUSE BLOCK NEG. BUS
SEE DWG
360-DC-1-1
LINE 4
360-DC-5
