Graef VA 804 - Machine Description

Operation
10
2. Description
2.1. Designation of the Machine Parts
Stop plate Blade cover plate
Blade
Thumb/finger guard Return lever
Carriage handle
Last slice clamp Last slice clamp handle
Carriage Guide rail
Locking screw
Chain frame handle
Chains
On button
Last slice clamp
Off button
Operator Slice thickness control
Start-stop button
Blade guard ring
Scraper Pressing roller
Thumb wheel Scraper comb
Placing arm star grip
Placing arm
(removable beater)
Tray
Power cable Tray guide
Carriage star grip
Feeder shaft
Bearing block
