Operation
12
2.3.Technical Dimensions
VA 802 VA 804 VA 806
Dimensions L x W x H 600 x 880 x 500 mm 600 x 1060 x 500 mm 600 x 1240 x 500
mm
Workspace L x W x H 700 x 920 x 640 mm 700 x 1100 x 640 mm 700 x 1280 x 640
mm
Minimum: 480 x 440 mmSpace occupied L x W
Ideal: 540 x 440 mm
Weight W Approx. 68 kg Approx. 70 kg Approx. 72 kg
Blade diameter D 300 mm
Blade speed N 229 rpm
Max. 250 x 180 mmDimensions with chain frame L x H
Min. 30 x 30 mm
Dimensions without chain
frame
L x H Max. 260 x 195 mm
Slicing length L 250 mm
Largest distance between last
slice clamp and blade
(clamping distance)
L 230 mm 420 mm 600 mm
Tray size L x W 300 x 255
Length of tray run s 160 mm
Slice thickness T 0.5 - 10 mm
Slicing speed maximum V Max. 70 strokes per
minute
Max. 60 strokes per
minute
Max. 55 strokes per
minute
Emissions – noise level acc. to
EN ISO 11204, at idling
Leq < 69 dB (A)
Vibration total value < 2,5m/s² (for VA 802H)
Power consumption P
1
[W]
Frequency f [Hz]
Current I [A]
Voltage U
N
[V]
See type plate
