GXV3380 Administration Guide
Version 1.0.1.19
P a g e | 56
SIP Realm used for
Challenge INVITE &
NOTIFY
Configure this item to validate incoming INVITE, but you must enable
authenticate incoming INVITE first to make it take effect. You can verify the
NOTIFY information for the provision, including check- sync, resync and
reboot, but only when SIP NOTIFY authentication enabled first to make it
take effect.
Upload Local MOH
Audio File
Loads the MOH (Music on Hold) file to the phone. Click on “Browse” button
to upload the music file from local PC. The MOH audio file has to be in .wav
or .mp3 format.
Note: Please be patient while the audio file is being uploaded. It could take
more than 3 minutes to finish the uploading especially the file size is large.
The button will show as “Processing” during the uploading. Once done, it
will show as “Browse” again. Click on “Save” on the bottom of the web
page and “Apply” on the top of the web page to save the change.
Plays local MOH file if the call is being hold by the phone.
Default setting is “No”.
It is used to set to categorize accounts in server mode groups, the accounts
in the same group will be combined as one and the account widget will
display the Caller ID in the account with lowest ID. The phone can answer
any incoming calls to each account in groups.
If user makes an outbound call, the phone system will use the lowest ID
account by default. If the account fails or SIP INVITE message is timeout,
the phone system will failover to the next account in the group with higher
account ID.
If all the accounts are not available in the group, the phone system will
traverse all the accounts in the group and notify the end users the session
is failed.
Configures phone’s settings to meet different vendors’ server
requirements. Users can choose from Standard, Broadsoft, China Mobile,
ZTE IMS, Mobotix, ZTE NGN, Huawei IMS, NEC or WorldStone depending
on the server type.
Allow Sync Phonebook
via SIP Notify
Allows users to synchronize XML phonebook upon receiving SIP NOTIFY
message with header Event: sync-contacts.
Note: Received SIP NOTIFY will be first challenged for authentication
purpose before contacting configured server to download XML phonebook.
The parameters used are the ones configured at [Download Contacts].
The authentication can be done either using admin credentials (if no SIP
account is configured) or using SIP account credentials.
The default setting is “Yes”.
