Grandstream Networks GXV3380

GXV3380 Administration Guide
Version 1.0.1.19
P a g e | 90
Duration
Displays the duration of the phone call
Date
Displays the date the call was recorded on
Operation
Delete, Modify or download the recording file
Normal Recording
File name
Displays the name of the recording file
Duration
Displays the duration of the phone call
Date
Displays the date the call was recorded on
Operation
Delete, Modify or download the recording file
Value-added Service Page Definitions
Value-added Service/Value-added Service (0/10)
Service Type
Users can set the service type to “Door System” to configure the door
system options, or to “DTMF” to set DTMF content to send it during calls.
Door System Type
Set the door system type to “GDS” if the GDS door system is used, or set
it to “Baudisch” if another door system brand is used.
Note: Each GDS door system has 2 different access passwords to control
2 doors separately named as [Related Display Name1] & [Related
Display Name2] below for door 1 and 2 respectively.
System Number
Specifies the door system number which is the SIP user ID configured on
door system or its IP address, if the door system is using IP call. It enables
to show open door button when caller number or IP address matches with
this setting. e.g:"36311" or "192.168.124.81".
Note: When set “Door System Type” to “Baudisch” a “configure” button will
appear to allow user to configure groups of door system URL and User ID
for 100 entries.
 System Number: This is used to configure the User ID of door system.
Once configured, only the call from this User ID would use door system
while other calls use the default mode.
 System Address: This is used to input the IP address or URL of the
system in order to identify the call from door system.
Users can set HTTP authentication credentials on the URL for Door
Systems that require authentication to send HTTP stream. The URL
format will be similar to the following:
http://username:password@192.168.1.150/goform/stream?cmd=get
&channel=4
