Grandstream Networks GXV3380

GXV3380 Administration Guide
Version 1.0.1.19
P a g e | 66
Layer 2 QoS
802.1Q/VLAN Tag
(Ethernet) for VoIP Calls
When Different Networks for Data and VoIP Calls set to Yes, then this
option will be applied for VoIP traffic. Assigns the VLAN Tag of the Layer
2 QoS packets for Ethernet for VoIP Calls. The Default value is 0.
Layer 2 QoS 802.1p
Priority Value (Ethernet)
for VoIP Calls
When Different Networks for Data and VoIP Calls set to Yes, then this
option will be applied for VoIP traffic. Assigns the priority value of the Layer
2 QoS packets for Ethernet for VoIP Calls. The Default value is 0.
The setting needs reboot to take effect.
802.1x Mode
802.1x mode
Enables and selects the 802.1x mode for the phone system. The supported
802.1x modes are: EAP-MD5, EAP-TLS, EAP-PEAP
The default setting is "Disable".
802.1x Identity
Enters the identity information for the selected 802.1x mode. (This setting
will be displayed only if 802.1 X mode is enabled).
802.1x Secret
Enters the secret for the 802.1x mode. This option will appear when 802.1x
mode is EAP-MD5 or EAP-PEAP.
CA Certificate
Uploads the CA Certificate file to the phone. (This setting will be displayed
only if the 802.1 X mode is enabled)
Client Certificate
Loads the Client Certificate file to the phone. (This setting will be displayed
only if the 802.1 X TLS mode is enabled)
Private Key
Loads the private key file to the phone. (This setting will be displayed only
if the 802.1 X TLS mode is enabled)
Network Settings/Wi-Fi Settings
Wi-Fi Basics
Wi-Fi Function
Enables/disables the Wi-Fi feature.
The default setting is "Disable".
WiFi Band
Sets the type of WiFi Band (2.4G & 5G, 2.4G or 5G).
The default setting is 2.4G&5G.
ESSID
Allows to scan and select the available Wi-Fi networks within the range if
the Wi-Fi feature is enabled. Click on "Select" to select the Wi-Fi network
to connect to. The ESSID will be auto filled in the ESSID filed.
Wi-Fi Security
ESSID
Determines the ESSID of the selected Wi-Fi network. It can be auto filled
by clicking the select button on the web page.
Password
Determines the password for the selected Wi-Fi network.
Security Mode for
Hidden SSID
Defines the security mode used for the wireless network when the SSID is
hidden. Default is “None”.
Advanced Settings
