Grandstream Networks GXV3380

GXV3380 Administration Guide
Version 1.0.1.19
P a g e | 88
Interval
download the phonebook file. It can be selected from the dropdown list:
 None
 5 Minutes
 30 Minutes
 1 Hour
 2 Hour
 4 Hour
 6 Hour
 8 Hour
 12 Hour
Download Now
Starts downloading the XML phonebook to the phone immediately.
Applications/LDAP Phonebook
Connection Mode
Selects which protocol will be used for LDAP searching, LDAP or LDAPS.
Default is “LDAP”.
Server Address
Configures the URI of the LDAP (Lightweight Directory Access Protocol)
server.
Port
Configures the LDAP server port. The default LDAP port number is 389.
Base DN
Determines the LDAP search base. This is the location in the directory
where the search is requested to begin.
Example:
dc=grandstream, dc=com
ou=Boston, dc=grandstream, dc=com
User Name
Configures the bind "Username" for querying LDAP servers. Some LDAP
servers allow anonymous binds in which case the setting can be left blank.
Password
Specifies the bind "Password" for querying LDAP servers. The field can be
left blank if the LDAP server allows anonymous binds.
LDAP Name Attributes
Configures the "name" attributes of each record which are returned in the
LDAP search result. This field allows the users to configure multiple space
separated name attributes.
Example:
cn sn description
LDAP Number
Attributes
Configures the "number" attributes of each record which are returned in the
LDAP search result. This field allows the users to configure multiple space
separated number attributes.
Example:
telephoneNumber
telephoneNumber Mobile
