This is the IP address of the configured TFTP server. If selected and it is
non-zero or not blank, the GXW400X retrieves the new configuration file or
new code image from the specified TFTP server at boot time. After 5
attempts, the system will timeout and then it will start the boot process using
the existing code image in the Flash memory. If a TFTP server is configured
and a new code image is retrieved, the new downloaded image is saved into
the Flash memory.
Note: Do NOT interrupt the firmware upgrade process (especially the
power supply) as this will damage the device. Depending on the network
environment this process may take up to 15 or 20 minutes.
The URL for the HTTP server used for firmware upgrade and configuration
via HTTP.
Note: If Auto Upgrade is set to No, GXW400X will only do HTTP download
once at boot up.
IP address or domain name of firmware server. That URL of the server that
hosts the firmware release. The default server is: fm.grandstream.com/gs
IP address or domain name of configuration server. The server hosts a copy
of the configuration file to be installed on the gateway. The default server is:
fm.grandstream.com/gs
The password used for encrypting the XML configuration file using OpenSSL.
This is required for the phone to decrypt the encrypted XML configuration file.
The user name needed to authenticate with the HTTP/HTTPS server.
The password needed to authenticate with the HTTP/HTTPS server.
