Section 2: Technical Data Page 9
Figure 2-3: 46-70 dimensions
PLAN VIEW
LEFT SIDE VIEW
RIGHT SIDE VIEW
28
287
CONDENSATE
DRAIN
FLOW
542
1078
1024
765
828
915
412
RETURN
