2.5 BOILER DIMENSIONS
Section 2: Technical DataPage 8
Figure 2-1: 15-26 dimensions
Figure 2-2: 26-46 dimensions
PLAN VIEW
LEFT SIDE VIEW
RIGHT SIDE VIEW
116
198
327
32
86
590
629
891
594
431
730
750
RETURN
FLOW
CONDENSATE OUTLET
(15-21 & 21-26)
CONDENSATE OUTLET
(26-35)
FLOW
RETURN
PLAN VIEW
LEFT SIDE VIEW
RIGHT SIDE VIEW
591
458
27
28
88
323
RETURN
FLOW
CONDENSATE
DRAIN
789
877
553
699
455
594
113
