Grasshopper 721DT - Foot Rest Block Installation

29
Fig. 11
Foot Rest Block
Tap Screw
98036
SL96, SL98 Series
or 9772 Decks
Fig. 10
Foot Rest Block
Tap Screw
98035
33, 34 or 95
Series Decks
FOOT REST BLOCK INSTALLATION
If installing a 33, 34 or 95 series deck on a 700
series tractor, install the foot rest blocks with
the wide end of block toward the front (refer
to Fig. 10).
If installing an SL96, SL98 series or 9772
deck on a 700 series tractor, install the foot
rest blocks with the narrow end of block to-
ward the front (refer to Fig.11).
