50
OPTIONAL HYDRAULIC LIFT ASSEMBLY
Item Order Description
No. No.
Item Order Description
No. No.
05-07088G
Rev. 12-16
1 290074 Pump – Hydraulic CCW w/Solenoid
144950 Solenoid Valve
2 281540 Square Key .125 x 1
3 775137 Plate – Hydraulic Pump Mount
4 645559 Mount – Hydraulic Pump
5 831429 Sheave
6 381390 Belt
7 253203 Whiz Bolt .375-16 x 1
8 253200 Whiz Bolt .375-16 x .75
9 644845 Oil Tank – Aux.
10 100728 Dipstick
11 603330 Fitting w/Strainer
12 363826 Fitting - Barb
13 821723 Hose – Vent
14 360080 Adapter Fitting
15 363846 Fitting Beaded Stem Swivel 90°
16 360053 Adapter
17 360082 Adapter Stem 90°
18 360062 Adapter Stem 90°
19 360044 Adapter O-Ring 90°
20 360043 Adapter O-Ring 45°
21 780507 Flow Restrictor
22 360045 Adapter M NPT/F O-Ring
23 360005 Adapter Tee NPT/Flare
24 821787 Hose – Hydraulic .375 x 17
25 821773 Hose – Hydraulic .375 x 22
26 821800 Hose – Hydraulic .5 x 21.5
27 280264 Hose Clamp – Spring .375 TOC
28 280266 Hose Clamp – Spring .5 TOC
29 290021 Cylinder – Hydraulic
290096 Cylinder Seal Kit
30 360052 Adapter M O-Ring/M Flare
31 424540 Hose Assembly .25 x 18.5
32 424545 Hose Assembly .25 x 23
33 887119 Pin – Cylinder Mount
34 257062 Washer .5 SAE
35 253066 Whiz Nut .5-13
36 263500 Retainer – External .5 x .042
37 261339 Clevis Pin .375 x .875 Sq. Shank
38 260648 Cotter Pin .125 x .5
39 253192 Whiz Bolt .312-18 x .75
40 253035 Whiz Nut .312-18
41 644915 Mount – Weight
42 323951 Counterweight
43 729691 Weight Cover
44 240151 Hook Bolt .375-16 x 6
45 253043 Whiz Nut .375-16
46 603804 Steering Lever Assembly w/Switch
(includes items 47-57)
47 824579 Steering Lever - Lower Rt.
48 824577 Lever - Offset Folding w/Switch
49 422508 Step Bushing .255 x .5 x .25
50 243035 Bolt .25-20 x 1.5
51 253850 Nut .25-20 - Lock
52 247130 Carriage Bolt .312 x .75
53 257019 Washer .25 - Hard
54 252858 Thumb Screw .312-18 3 Prong
55 422095 Vinyl Cap
56 422179 Handle Grip - Foam
57 604799 Switch/Mount Assembly
58 645204 Cross Member - Center Hyd.
To Next Page
