Item Description
Ref. No. Qty
Remarks
COMPRESSOR HOUSING WITH CONNECTIONS
FIG. RC6-1
1
1.1A
1.1B
1.2
1.3A
1.3B
2
2.1
2.2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Cylinder head cover assy
Cylinder head cover RC6-2CR
Cylinder head cover RC6-2CR
Cylinder head cover RC6-1CR
Cylinder head cover RC6-1CR
Hex. head bolt M10x120
Oilit gasket 190x405x1.5-2CR
Oilit gasket 190x405x1.5-1CR
Cylinder head cover assy
Cylinder head cover RC6-0CR
Cylinder head cover RC6-0CR
Oilit gasket 190x405x1.5-0CR
Hex. head bolt M10x100
Hex. head bolt M10x120
Washer M10
Crankcase
Oilit gasket 175x290x1.5
Inspection side cover 175x290
Inspection side cover 175x290WK
Hex. head bolt M10x40
O-ring 2.62x32.99
Sight glass 2.9x60
Hex. head bolt M6x16
Eye bolt M16
Safety relief valve 26 5G33
Plug G13S
Crankcase heating element
Stop valve TAH8-12
Oil return orifice
Alu sealing ring 21x25x1
Plug G21
Plug G21
Alu sealing ring 21x27x2
Alu sealing ring 13,5x20x1
Nipple coupling 12G13
Nipple coupling 12G21
*
23.36.521
23.36.525
23.36.510
23.36.515
01.10.512
09.07.192
09.07.191
*
23.36.500
23.36.505
09.07.190
01.10.510
01.10.512
11.13.501
*
09.07.175
05.30.175
05.30.178
01.10.540
09.52.284
12.24.029
01.10.316
01.18.812
12.49.333
01.36.134
13.72.203
06.07.011
01.23.139
09.12.021
01.36.216
01.36.216
09.14.023
09.12.014
03.38.131
03.38.211
—
—
—
—
—
2
—
—
—
—
—
20
20
36
1
1
2
2
16
1
1
3
2
1
5
1
1
2
2
3
1
1
5
1
1
with capacity control
with cap. control for 2 cyl.
RC6W: with cap. control for 2 cyl.
with cap. control for 1 cyl.
RC6W: with cap. control for 1 cyl.
on item 1.1A
on item 1.1B
without capacity control
on type RC6W only
18 on item 1 (for RC6 types only)
18 on item 1 (for RC6W types only)
RC6 (2x), RC6W (1x)
RC6W (1x)
if connection not in use
in RC46(W) compressor only
in types RC66(W) & RC86(W)
MAIN BEARINGS
FIG. RC6-2
1
2
2.1
2.2
2.3
2.4
3
4
5
Flange bearing 60x15x11.5
Bearing assy
Pump housing RC6
O-ring 3.53x209.14
Flange bearing 60x50xM10
Socket head screw M10x100
Washer M10
Hex. head bolt M10x40
Hex. head bolt M10x35
11.43.600
*
––––-
09.52.365
11.43.651
01.04.510
11.13.501
01.10.540
01.10.535
1
1
1
1
1
4
16
8
8
driving end
refer to page 9
oil pump end from 95.08.1648
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC6
C2 RC6 0089238-v004.00.02.en
