Grasso RC6 - Suction and Discharge Valve

Item Description
Ref. No. Qty
Remarks
SUCTION AND DISCHARGE VALVE
FIG. RC6-5
1
2
3
4
5
5.1
5.2
5.3
5.4
5.5
5.6
5.7
6
7
8
9
10
11
12L
12H
13
Hex. head bolt M10x40
Washer M10
Pressure ring RC6
Sinusoidal buffer spring 87x124x4
Discharge valve assy RC6
Locking nut M8
Washer M8
Discharge valve stroke limitor
Sinusoidal spring 64x76x0.5
Discharge valve ring 64x76x1
Suction stroke limitor
Fitted bolt M8x40
Damper ring 108x87x4
Sinusoidal spring 88x108x0.7
Suction valve ring 88x108x0.7
O-ring 3.53x117.07
Cylinder liner 85RC6
O-ring 3.53x91.67
Discharge valve ring and spring(s) Option L
Discharge valve ring and spring(s) Option H
Suction valve ring, spring and damper ring
01.10.540
11.13.501
27.36.410
11.33.087
27.36.113
27.36.103
01.45.400
11.13.401
*
*
*
*
*
*
*
*
09.52.362
23.36.120
09.52.361
11.34.110
11.34.105
11.34.115
4
4
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
Option ’L’(Low)
Option ’H’(High)
refer
table
below
Option ’L’ (Low)
Option ’H’(High)
Source of table below; 00.87.315
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC6
C6 RC6 0089238-v004.00.02.en
