Figures
All parts shown in the figures bear an item number.
Assemblies are indicated by a dotted frame with
separate item number around the parts included in
that particular assembly;
the parts themselves bear the same item number,
followed by a sequence number (e.g. 2.1, 2.3, 2.3, etc.).
Parts lists
The parts are specified by the headings “Item”,
“Description” “Ref. no.” and “Qty” (= Quantity).
* If an asterisk is used instead of the Ref. no., this me-
ans that the relevant part cannot be obtained separa-
tely.
When for some part no quantity has been given, the
quantity required depends on the compressor size.
When determining the required quantity of parts, it
should be considered that the listed quantities relate
to the corresponding figure and not to the compres-
sor as a whole. When ordering, for example, valve
rings for two discharge valves, the quantities stated
in the relevant list must be doubled, because these
apply to one discharge valve only.
RC6W
This is a RC6 compressor, including water cooled cylin-
der heads
The illustrated parts list on the following pages is meant for identification and accurate specification of
spare parts. In order to facilitate quick retrieval of the required parts, the list and corresponding figures
is divided into the following groups of parts:
GROUP OF PARTS PARTS LIST
Page:
CORRESPONDING FIGURE
No.:
• Compressor housing with connections
2RC6-1
• Main bearings
2RC6-2
• Crankshaft
5RC6-3
• Piston and connecting rod
5RC6-4
• Suction and discharge valve
6RC6-5
• Rotary shaft seal
9RC6-6
• Oil pump
9RC6-7
• Capacity control mechanism
10 RC6-8
• Oil discharge filter
10 RC6-9
• Flanged main connections
13 RC6-10
• Suction gas strainer
13 RC6-11
• Oil suction filter
14 RC6-12
• Oil differential pressure safety switch
14 RC6-13
• Oil pressure regulator
14 RC6-14
• Standard sets of parts and seals
16 ---------
How to order!
It is emphatically pointed out that a prompt despatch of the correct spare parts can be
guaranteed only if the following information is given:
1. Type designation of the compressor
2. Serial number of the compressor
shown on the compressor name plate
3. Quantity, Description and Ref. No. of the required parts.
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC6
0089238-v004.00.02.en RC6 C1
