Grasso RC6 - Flanged Main Connections; Suction Gas Strainer

Item Description
Ref. No. Qty
Remarks
FLANGED MAIN CONNECTIONS
FIG. RC6-10
1A
1B
1C
2
3
4
Shoulder flange RC46
Shoulder flange RC66
Shoulder flange RC86
Hex. head bolt M16x40
Oilit ring 67x81x1.5
Relief valve
05.39.045
05.39.051
05.39.063
01.10.840
09.03.067
12.49.333
1
1
1
4
1
per flanged connection
per flanged connection
SUCTION GAS STRAINER
FIG. RC6-11
1A
1B
2
3
Shoulder flange RC46
Shoulder flange RC66/RC86
Oilit ring 67x81x1.5
Wired mesh filter 544x100
05.39.048
05.39.060
09.03.067
07.16.544
1
1
2
1
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC6
0089238-v004.00.02.en RC6 C13
