Grasso RC6 - Oil Suction Filter; Oil Differential Pressure Safety Switch; Oil Pressure Regulator

Item Description
Ref. No. Qty
Remarks
OIL SUCTION FILTER
FIG. RC6-12
1
2
Oil filter 149x16
Swivel coupling 16G21
07.16.164
03.39.216
1
1
from 95.08.1648
OIL DIFFERENTIAL PRESSURE SAFETY SWITCH
FIG. RC6-13
1
2
3
4
5
6
7
8
Oil pressure safety switch
Bracket 63x115
Angle coupling 6x6x6 (complete)
Socket coupling 6G17 (complete)
Union nut
Steel precision pipe ø6x1 mm
Nipple coupling 6G10
Clamp but sleeve P6
12.60.232
12.61.232
*
03.40.406
03.37.176
03.10.006
*
03.38.106
*
1
1
1
2
2
6
2
1
8
NH3
R
Possibly 6N13 (03.38.813) or 6G13
(03.38.136) are applied
OIL PRESSURE REGULATOR
FIG. RC6-14
1
1.1
1.2
1.3
1.4
1.5
1.6
1.7
1.8
1.9
2
3
Oil return line SAM RC6
Steel precision pipe K12x1.5 and valve housing
Alu sealing ring 21.5x27x1
Ball W16
Spring 1.25x14x9x35.5
Thrust bolt G21x60S
O-ring 1.78x8.73
Nipple G21CxG21
Alu sealing ring 10x18x1
Cap nut GK21R
Nipple coupling 12G13
Nipple coupling 12G21
12.41.140
12.41.012
09.12.022
11.19.010
11.31.134
01.35.218
09.52.184
03.04.921
09.12.010
01.17.021
----------
----------
1
1
1
1
1
1
1
1
1
1
1
1
lubricating oil pressure regulator
included
refer to fig. RC6-6
refer to fig. RC6-1
Refrigeration Division
Grasso
STANDARD ILLUSTRATED PARTS LIST RC6
C14 RC6 0089238-v004.00.02.en
