GRAUPNER mx-16 ifs User Manual

9
Description of radio control system
Specifi cation
of mx-16iFS transmitter
Frequency band 2,4 … 2,4835 GHz
Intelligent Frequency Select
Transmitter output
power
Please refer to the table
on page 126 for details of
approved output powers in
individual countries.
Control functions 8 functions, 4 with trims
Servo resolution 65,536 steps (16 bit)
Temperature range -15 … +55°C
Aerial SMA connector, folding,
removable
Operating voltage 9,6 … 12 V
Current drain approx. 185 mA
Dimensions approx. 190 x 195 x 85 mm
Weight approx. 850 g with Transmitter Bat-
tery
Accessories
Order No. Description
1121 Neckstrap, 20 mm wide
70 Neckstrap, 30 mm wide
3097 Wind-shield for hand-held transmitter
See page 124 for
mx-16iFS Trainer leads
Replacement parts
Order No. Description
23050 iFS transmitter aerial
Specifi cation of XR-16ifs receiver
Operating voltage 4,8 … 6 V
Current drain approx. 70 mA
Frequency band 2,4 … 2,4835 GHz
National settings The approved national set-
tings are listed in the table
on page 126, and also in the
instructions supplied with the
receiver.
Servo resolution 65,536 steps (16 bit)
servo signal accuracy ±10 ns
Aerial Length approx. 3 cm, com-
pletely enclosed in receiver
case
Servo functions 8
Temperature range -15° … +55° C
Dimensions approx. 54 x 29 x 14 mm
Weight approx. 19 g
The sets contain
Order No. 23000:
mx-16iFS micro-computer synthesizer transmitter with
integral 8NH-2000 TX NiMH battery (type may differ),
XR-16ifs 2.4 GHz bi-directional receiver, one DS 8077
servo, switch harness
Order No. 23000.99:
mx-16iFS micro-computer synthesizer transmitter with
integral 8NH-2000 TX NiMH battery (type may differ),
XR-16ifs 2.4 GHz bi-directional receiver
Please refer to the table on page 126 for details of approved transmit-
ter power outputs in individual countries.
