Jaguar II User Manual

1.3 Back View of Jaguar (Figure 1-2)

Lever - raises o

lowers the pinc

rollers.

Pinch Rollers - hol

the media during cutting.

1.4 Whole View of Jaguar (

Figure 1-3)

e body.

Roll Holder

Support – supports

roll holders

Stand Beam –

stabilizes th

Stand - Supports the

cutting plotter body.

Roll Holder Guide

Bushes - Serve to keep the

roll media in place whe

media is pulled from the

roll.

Roll Holder - Holds an

supplies the roll media

for cutting.

H-shape Stand – Supports the

cutting plotter body.

Figure 1-3

Figure 1-2

1 – Setting Up Your sign Cutting Plotter 1-3
