GReddy Profec - Installation Procedures; Overview and Wiring Instructions

Sensorunit
4Φhose
SolenoidValveUnit
ChassisGround
+12VACC(Accessory)Power
Driverʼscompartment
EngineBay
Controlunit
Filter
FuelPressureRegulator
Actuator
Turbine
Aircleaner
Intercooler
Engine
Throttle
InstallationOverview (Actuatortype)
TheProfecSensorunitiswaterproofandcanbesafelymountedintheenginebay.
Onlyonemainharnesslineisrequiredtoberoutedthroughthefirewalltothe
driverʼscompartment.Thecontrolunitisonlywaterresistant.Therefore,donot
installitinalocation,whereitcouldgetwetorbeinexcessiveheat.
IInstallinacoolplace
avoidingdirectsunlight.
Installation
Itispossibletoconnectthe
Solenoidvalveunitdirectlytothe
Sensorunit,withoutusingthe
solenoidvalveharness.
