GReddy Profec - Installing the Solenoid Valve Unit - Twin Actuator Type

■TwinTurboVehicles■
1
2
Installingthesolenoidvalveunit‒(TwinActuatorType)
Actuators
Turbocompressor
pressuresources
Installation
Fortwinturboapplications,two“Y”connectorswillberequired.However,the
installationprocedureisthesameasPage12.Placea“Y”connectortoconnectthe
[1]portofthesolenoidvalvetothetwoportsforTurbinecompressorasshownin
thediagramabove.Thesameappliesforthe[2]portofthesolenoidvalve,usea“Y”
connectortoconnectthetwowastegateactuators.
