DC INVERTER MULTI VRF PRODUCT
16
Model GMV(L)-R90P/Na-K GMV(L)-R100P/Na-K GMV(L)-R112P/Na-K
kW 9.0 10.0 11.2
Cooling Capacity
Btu 30709 34121 38216
kW 10.0 11.0 12.5
Heating Capacity
Btu 34120 37532 42650
m3/h 2000 2000 2000
Air Flow Rate
CFM 1177 1177 1177
Sound Pressure Level (H/L) dB(A) 44/40 44/40 44/40
External Static Pressure Pa 100 100 100
Power Supply
220-240V～50Hz 220-240V～50Hz 220-240V～50Hz
Output kW 0.225 0.225 0.225
Fan Motor
Running Current A 2.14 2.14 2.14
mm
φ15.9 φ15.9 φ15.9
Gas Pipe
inch
5/8＂ 5/8＂ 5/8＂
mm
φ9.52 φ9.52 φ9.52
Liquid Pipe
inch
3/8＂ 3/8＂ 3/8＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes（External Dia. ×
Thickness）
mm
φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions
(W×D×H)
mm
1385×736×300 1385×736×300 1385×736×300
Package Dimensions
(W×D×H)
mm
1514×795×360 1514×795×360 1514×795×360
Weight（Net/Gross）
kg 75/79 75/79 75/79
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
