DC INVERTER MULTI VRF PRODUCT
15
Model GMV(L)-R63P/Na-K GMV(L)-R71P/Na-K GMV(L)-R80P/Na-K
kW 6.3 7.1 8.0
Cooling Capacity
Btu 21496 24226 27297
kW 7.0 8.0 8.8
Heating Capacity
Btu 23884 27296 30026
m3/h 1400 1400 1400
Air Flow Rate
CFM 824 824 824
Sound Pressure Level (H/L) dB(A) 42/38 42/38 42/38
External Static Pressure Pa 100 100 100
Power Supply
220-240V～50Hz 220-240V～50Hz 220-240V～50Hz
Output kW 0.15 0.15 0.15
Fan Motor
Running Current A 1.32 1.32 1.32
mm
φ15.9 φ15.9 φ15.9
Gas Pipe
inch
5/8＂ 5/8＂ 5/8＂
mm
φ9.52 φ9.52 φ9.52
Liquid Pipe
inch
3/8＂ 3/8＂ 3/8＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm
φ30×1.5 φ30×1.5 φ30×1.5
Unit Dimensions
(W×D×H)
mm
1112×756×300 1112×756×300 1112×756×300
Package Dimensions
(W×D×H)
mm
1245×785×360 1245×785×360 1245×785×360
Weight（Net/Gross）
kg 55/59 55/59 55/59
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling
only units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little
higher in actual operation.
