DC INVERTER MULTI VRF PRODUCT
35
4.2.4Floor Ceiling Type
Model GMV(L)-R28Zd/Na-K GMV(L)-R36Zd/Na-K GMV(L)-R50Zd/Na-K
kW 2.8 3.6 5.0
Cooling Capacity
Btu 9554 12284 17061
kW 3.2 4.0 5.8
Heating Capacity
Btu 10919 13649 19790
m3/h 550 600 700
Air Flow Rate
CFM 324 353 412
Sound Pressure Level
(H/L)
dB(A) 43/- 44/- 50/-
External Static Pressure Pa 0 0 0
Power Supply 220-240V~50Hz 220-240V~50Hz 220-240V~50Hz
Output kW 0.01 0.01 0.04
Fan Motor
Running
Current
A 0.1 0.1 0.4
mm Φ9.52 Φ12.7 Φ12.7
Gas Pipe
inch
3/8＂ 1/2＂ 1/2＂
mm Φ6.35 Φ6.35 Φ6.35
Liquid
Pipe
inch
1/4＂ 1/4＂ 1/4＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection Flare Connection
Drain Pipes
（External Dia. ×
Thickness）
mm
Φ17×1.75 Φ17×1.75 Φ17×1.75
Unit Dimensions
(W×D×H)
mm 840×238×695 840×238×695 840×238×695
Package Dimensions
(W×D×H)
mm 1035×295×805 1035×295×805 1035×295×805
Weight（Net/Gross）
kg 28/37 28/37 28/37
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling only
units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little higher in
actual operation.
