DC INVERTER MULTI VRF PRODUCT
36
Model GMV(L)-R71Zd/Na-K GMV(L)-R90Zd/Na-K
kW 7.1 9.0
Cooling Capacity
Btu 24226 30709
kW 8.0 10.0
Heating Capacity
Btu 27297 34121
m3/h 1170 2100
Air Flow Rate
CFM 689 1236
Sound Pressure Level (H/L) dB(A) 48/- 51/-
External Static Pressure Pa 0 0
Power Supply
220-240V～50Hz 220-240V～50Hz
Output kW 0.1 0.15
Fan Motor
Running Current A 1 1.5
mm Φ15.9 Φ15.9
Gas Pipe
inch
5/8＂ 5/8＂
mm Φ9.52 Φ9.52
Liquid Pipe
inch
3/8＂ 3/8＂
Connecting
Pipes
Connection Method Flare Connection Flare Connection
Drain Pipes
（External Dia. × Thickness）
mm
Φ17×1.75
Φ17×1.75
Unit Dimensions
(W×D×H)
mm 1300×188×600 1590×238×695
Package Dimensions
(W×D×H)
mm 1514×248×724 1714×330×830
Weight（Net/Gross）
kg 34/38 44/53
Notes:
① Refer to the product nameplate for parameters and specification of the unit;
② The model with GMVL code is cooling only unit; while the model with GMV code is heat pump unit; the cooling only
units dose not have any parameters of performing heating;
③ The sound level was tested under circumstance of semi-anechoic chamber; the value of noise could be a little higher in
actual operation.
