Gree FLEXX Series Service Manual

GREE DC INVERTER HEAT PUMP CONDENSING UNIT
109
No.
Material name
10
Rear Side Plate
11
Centrifugal Fan Assy
12
Motor For Centrifugal Fan
13
Brushless DC Motor
14
Top Cover Board Sub-Assy
15
Bottom Cover Plate Assy
16
Right Side Plate
17
Bottom Cover Plate Assy
18
Water Tray
19
Strainer
20
Cut-Off Valve 3/8(N)
21
Thermal Expansion Valve
22
Cut Off Valve
23
Evaporator Assy
24
Evaporator Assy
25
Evaporator Assy
26
Water Tray Assy
27
Choke Plug
28
Water Tray
29
Filter Sub-Assy

Gree FLEXX Series Specifications

General

Type	Heat Pump
Series	FLEXX
SEER	Up to 20
HSPF	Up to 10
Refrigerant	R410A
Heating Operation Range	-22°F to 75°F
Cooling Operation Range	5°F to 122°F
Operating Temperature Range (Heating)	-22°F to 75°F
Operating Temperature Range (Cooling)	5°F to 122°F
Energy Efficiency Ratio (EER)	Up to 12.5
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Compressor Type	Inverter
Power Supply	208/230V, 1Ph, 60Hz
Noise Level	As low as 55 dB(A)
