Gree FLEXX Series Service Manual

GREE DC INVERTER HEAT PUMP CONDENSING UNIT
110
Appendices
1 Resistance/Temperature Lists of Temperature Sensors
1.1 Voltage List of 15 KΩ Temperature Sensors (including ODU
temperature sensors)
Temperature (℃)
Resistance (kΩ)
Voltage (V)
Temperature (℃)
Resistance (kΩ)
Voltage (V)
-20
144
0.311
71
2.523
2.825
-19
138.1
0.323
72
2.439
2.838
-18
128.6
0.345
73
2.358
2.852
-17
121.6
0.362
74
2.28
2.865
-16
115
0.381
75
2.205
2.877
-15
108.7
0.4
76
2.133
2.889
-14
102.9
0.42
77
2.064
2.901
-13
97.4
0.44
78
1.997
2.912
-12
92.22
0.462
79
1.933
2.923
-11
87.35
0.484
80
1.871
2.934
-10
82.75
0.506
81
1.811
2.945
-9
78.43
0.53
82
1.754
2.955
-8
74.35
0.554
83
1.699
2.964
-7
70.5
0.579
84
1.645
2.974
-6
66.88
0.605
85
1.594
2.983
-5
63.46
0.631
86
1.544
2.992
-4
60.23
0.658
87
1.497
3.001
-3
57.18
0.686
88
1.451
3.009
-2
54.31
0.714
89
1.408
3.017
-1
51.59
0.743
90
1.363
3.025
0
49.02
0.773
91
1.322
3.033
1
46.8
0.801
92
1.282
3.04
2
44.31
0.835
93
1.244
3.047
3
42.14
0.866
94
1.207
3.054
4
40.09
0.899
95
1.171
3.061
5
38.15
0.931
96
1.136
3.068
6
36.32
0.965
97
1.103
3.074
7
34.58
0.998
98
1.071
3.08
8
32.94
1.033
99
1.039
3.086
9
31.38
1.067
100
1.009
3.092
10
29.9
1.102
101
0.98
3.098
11
28.51
1.138
102
0.952
3.103
12
27.18
1.174
103
0.925
3.108
13
25.92
1.21
104
0.898
3.114
14
24.73
1.246
105
0.873
3.119

Gree FLEXX Series Specifications

General

Type	Heat Pump
Series	FLEXX
SEER	Up to 20
HSPF	Up to 10
Refrigerant	R410A
Heating Operation Range	-22°F to 75°F
Cooling Operation Range	5°F to 122°F
Operating Temperature Range (Heating)	-22°F to 75°F
Operating Temperature Range (Cooling)	5°F to 122°F
Energy Efficiency Ratio (EER)	Up to 12.5
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Compressor Type	Inverter
Power Supply	208/230V, 1Ph, 60Hz
Noise Level	As low as 55 dB(A)
