Gree FLEXX Series Service Manual

GREE DC INVERTER HEAT PUMP CONDENSING UNIT
117
2 Temperature/Pressure List of Refrigerant
R410A
Temperature
Pressure
Temperature
Pressure
Temperature
Pressure
℃
kPa
℃
kPa
℃
kPa
-30
275
0
803
30
1880
-29
286
1
823
31
1910
-28
298
2
851
32
1960
-27
311
3
879
33
2030
-26
324
4
903
34
2080
-25
334
5
937
35
2130
-24
348
6
962
36
2180
-23
363
7
994
37
2240
-22
375
8
1020
38
2290
-21
391
9
1050
39
2350
-20
404
10
1090
40
2410
-19
424
11
1110
41
2460
-18
435
12
1150
42
2510
-17
453
13
1180
43
2580
-16
468
14
1220
44
2650
-15
483
15
1250
45
2710
-14
504
16
1280
46
2770
-13
520
17
1320
47
2840
-12
538
18
1350
48
2910
-11
556
19
1400
49
2980
-10
579
20
1440
50
3050
-9
598
21
1470
51
3100
-8
618
22
1520
52
3180
-7
639
23
1560
53
3250
-6
660
24
1600
54
3320
-5
682
25
1640
55
3400
-4
705
26
1680
56
3480
-3
728
27
1730
57
3540
-2
752
28
1780
58
3630
-1
777
29
1820
59
3720
3 Operation Tools
The following tools will be used: 1) Liquid-level gauge; 2) Screwdriver; 3) Electric driven rotary hammer; 4)
Drill; 5) Pipe expander; 6) Torque wrench; 7) Open-end wrench; 8) Pipe cutter; 9) Leak detector; 10) Vacuum
pump; 11) Pressure gauge; 12) Universal meter; 13) Hexagon wrench; 14) Tapeline.

Gree FLEXX Series Specifications

General

Type	Heat Pump
Series	FLEXX
SEER	Up to 20
HSPF	Up to 10
Refrigerant	R410A
Heating Operation Range	-22°F to 75°F
Cooling Operation Range	5°F to 122°F
Operating Temperature Range (Heating)	-22°F to 75°F
Operating Temperature Range (Cooling)	5°F to 122°F
Energy Efficiency Ratio (EER)	Up to 12.5
Dimensions (Outdoor Unit)	Varies by model
Weight (Outdoor Unit)	Varies by model
Compressor Type	Inverter
Power Supply	208/230V, 1Ph, 60Hz
Noise Level	As low as 55 dB(A)
