G36p
Oxygen Analyzer
Version 2.11 – Revision March 2022 23
Commissioning
Commissioning gives access to the settings of the basic display including Date and Time,
Auto returns, and Alarm logbook. For parameter settings - see section 5.1.
Calibrate Touch Panel
The touch panel requires calibration every time the user reloads the factory settings.
To calibrate select the Calibrate touch panel and follow the instructions on the screen, i.e.
hitting the cross hairs when they appear on the screen.
• If the touch panel is calibrated correctly, i.e. that means it is hit the cross hairs on the
screen; the message Saved – hit the touch panel will appear. Complete the calibration
by touching the panel one more time.
• If the touch panel is calibrated incorrectly, i.e. you have not hit all the cross hairs, the
display will show the message Error try again – hit the touch panel. In this case, it is
important to calibrate the touch panel again.
Please note that it can be useful to calibrate the touch panel using a small pointed object
such as a pencil. However, the pointed object can be too sharp and can damage the touch
screen. Thus, do not push it too hard.
Service (requires an access password)
• Password level 1 is 9490. This gives you access to the analyzer configuration includ-
ing Alarm setup and Analog input/out setup. For details of these settings - see sec-
tions 5.2, 5.3, and 5.4.
• Password level 2 gives access to two other functions: Load factory settings and Load
default settings. For password level 2, see the Testing & Configuration Sheet deliv-
ered with each analyzer.
Please see the inside cover (Figure 1) for the overview of the program menu structure.
