G36p
Oxygen Analyzer
Version 2.11 – Revision March 2022 9
3 Installation & Connections
Read this chapter in its entirety before installing the analyzer.
3.1 Control at Delivery
When you receive the G36p Oxygen Analyzer, control that the received scope of supply
is in accordance with the packing list and nothing is damaged. Any discrepancy should be
reported to the supplier immediately. If any of the received parts are damaged, the ship-
ping company should be informed, and new parts should be made available before com-
pleting the installation
3.2 Where to Install the Analyzer
The G36p is designed for front mounting in control panels. To obtain IP55 tightness, the
included gasket must be mounted between the hole that is cut in the panel and the display
front.
Satisfactory operation, faultless functions, and minimal maintenance of the G36p are
achieved by paying attention to the following notes:
• The equipment should be installed in a clean area away from dust, oil mist, and mois-
ture. The analyzer should be installed at viewing level in an area with good access for
operating and servicing. The location and installation of the analyzer must be chosen,
so that the ambient temperature is below 70C at any time.
• The gasses supplied to the sensor must have a constant flow and pressure. This flow
and pressure control is achieved with the sampling system that is typically delivered
with the analyzer. Please consult the respective manual or contact Green Instruments
A/S.
• The sensor houses for both SEN1 and SEN9 have 1/8” BSP connection. Sampling
tube and vent line should be arranged in the way which ensures the flow and pressure
at sensor house constant and within the required range.
• The sensor can be installed up to 6 m from the analyzer. The sensor and the sensor
house shall be mounted horizontally (sensor pointing sideways) or downwards (sen-
sor pointing down) to prevent the water condensation collecting at the sensor house.
