Greenlee 555 - Special Bending Information Chart (Continued); Rigid;IMC Conduit Bending Data

Greenlee Textron / Subsidiary of Textron Inc.
23
4455 Boeing Dr., Rockford, IL 61109-2988 815/397-7070
555 Electric Bender
1 RIGID/ IMC Dia. = 1.315 Radius = 5.92 X = 3.42
Y 15 0.99 8.72 16.44 24.17 31.90 39.62 51.22 62.81 85.99 132.35
L1 15 7.72 15.45 23.17 30.90 38.63 46.36 57.95 69.54 92.72 139.08
L2 15 9.27 17.00 24.72 32.45 40.18 47.91 59.50 71.09 94.27 140.63
Z 15 12.44 19.91 27.37 34.84 42.30 49.76 60.96 72.16 94.55 139.33
MINIMUM H = 1.29
Y 22.5 4.14 9.36 14.59 19.82 25.04 32.88 40.72 56.40 87.76
L1 22.5 10.42 15.65 20.87 26.10 31.33 39.17 47.01 62.68 94.04
L2 22.5 12.75 17.97 23.20 28.43 33.65 41.49 49.33 65.01 96.37
Z 22.5 15.43 20.26 25.09 29.92 34.75 41.99 49.23 63.72 92.69
MINIMUM H = 2.21
Y 30 1.68 5.68 9.68 13.68 17.68 23.68 29.68 41.68 65.68
L1 30 7.93 11.93 15.93 19.93 23.93 29.93 35.93 47.93 71.93
L2 30 11.03 15.03 19.03 23.03 27.03 33.03 39.03 51.03 75.03
Z 30 13.52 16.98 20.45 23.91 27.38 32.57 37.77 48.16 68.95
MINIMUM H = 3.30
Y 45 1.68 4.51 7.34 10.17 14.41 18.65 27.14 44.11
L1 45 8.23 11.06 13.89 16.72 20.96 25.20 33.69 50.66
L2 45 12.88 15.71 18.54 21.37 25.61 29.85 38.34 55.31
Z 45 14.32 16.32 18.32 20.32 23.32 26.32 32.32 44.32
MINIMUM H = 5.89
Y 60 1.64 3.95 6.26 9.72 13.19 20.12 33.97
L1 60 10.91 13.22 16.68 20.15 27.08 40.93
L2 60 17.11 19.42 22.88 26.35 33.28 47.13
Z 60 16.03 17.18 18.92 20.65 24.11 31.04
MINIMUM H = 8.81
Y 90 2.00 5.00 8.00 14.00 26.00
L1 90 15.46 21.46 33.46
L2 90 24.76 30.76 42.76
Z90 15.26 15.26 15.26
MINIMUM H = 15.26
1-1/4 RIGID/IMC Dia. = 1.66 Radius = 7.47 X = 4.45
Y 15 6.81 14.54 22.27 30.00 37.72 49.32 60.91 84.09 130.45
L1 15 7.72 15.44 23.17 30.90 38.63 46.35 57.94 69.54 92.72 139.08
L2 15 9.67 17.40 25.13 32.85 40.58 48.31 59.90 71.49 94.67 141.04
Z 15 13.88 21.35 28.81 36.27 43.74 51.20 62.40 73.59 95.99 140.77
MINIMUM H = 1.66
Y 22.5 2.35 7.57 12.80 18.03 23.25 31.09 38.93 54.61 85.97
L1 22.5 10.41 15.64 20.87 26.09 31.32 39.16 47.00 62.68 94.03
L2 22.5 13.35 18.57 23.80 29.03 34.25 42.09 49.93 65.61 96.97
Z 22.5 17.08 21.91 26.74 31.56 36.39 43.63 50.88 65.36 94.33
MINIMUM H = 2.84
Y 30 3.89 7.89 11.89 15.89 21.89 27.89 39.89 63.89
L1 30 11.91 15.91 19.91 23.91 29.91 35.91 47.91 71.91
L2 30 15.82 19.82 23.82 27.82 33.82 39.82 51.82 75.82
Z 30 18.85 22.31 25.77 29.24 34.43 39.63 50.02 70.81
MINIMUM H = 4.23
Y 45 2.68 5.42 8.25 12.50 16.74 25.22 42.19
L1 45 10.99 13.82 16.65 20.89 25.13 33.62 50.59
L2 45 16.86 19.69 22.52 26.76 31.00 39.49 56.46
Z 45 18.64 20.64 22.64 25.64 28.64 34.64 46.64
MINIMUM H = 7.52
Y 60 1.83 4.14 7.60 11.06 17.99 31.85
L1 60 13.05 16.52 19.98 26.91 40.77
L2 60 20.88 24.34 27.80 34.73 48.59
Z 60 20.00 21.74 23.47 26.93 33.86
MINIMUM H = 11.32
Y 90 2.25 5.25 11.25 23.25
L1 90 20.79 32.79
L2 90 32.53 44.53
Z90 19.39 19.39
MINIMUM H = 19.39
HEIGHT – H
DIM ANGLE 2" 4" 6" 8" 10" 12" 15" 18" 24" 36"
Special Bending Information Chart (cont’d)
