GRESGYING F2-EU - 2.5 List of Tools

12 / 52
Standard
IEC61851-1 / IEC62196-3
User Interface & Control
User authentication
APP, QR Code (optional), RFID
HMI
7-inch touch LCD
SOC State Display
Available
Connectivity
Ethernet/4G (optional)
Communication protocol
OCPP 1.6J
Mechanical Parameters
Cable length
4.5m
Dimension(W*D*H)
700mmx400mmx1550mm
Gross Weight
150kg
Protection
IP54, IK10
Environmental
Storage Temperature
-40 to 70℃ ambient
Operating Temperature
-20 to 50℃ ambient
Operating Humidity
5%~95% ( no condensation)
Altitude
≤2000m
Cooling Method
Forced Air Cooling
Noise
≤60dB
2.5 List of Tools
Below is the list of the tools required (not included) to install the Gresgying DC60kW
charging station:
 Iron crowbar
 Needle nose pliers
 Utility knife
 Phillips screwdriver
 M12*100 expansion screw
CAUTION:
Some operations described in this manual may require a ladder or a stepladder.
Refer to your local regulation regarding the working height and relevant safety instructions.
