GRESGYING F2-EU - 6.5 Cooling

23 / 52
Note:
Bollards should not interfere with the clearance around the charger.
6.5 Cooling
The air inlet is located on the right door of the cabinet, and the air outlet is located on the
left door of the cabinet. The ventilation in the cabinet must meet the requirements of 1400
m3/h.
1. Air inlet; 2. Air outlet
