Model G0725 (Mfd. Since 03/18)
-13-
Inventory
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
Jointer Inventory: (Figures
4–5)
Qty
A. Jointer Bed Assembly................................. 1
B. Fence.......................................................... 1
C. Dust Collection Bag .................................... 1
D. Push Blocks ................................................ 2
E. Fence Tilting Handle .................................. 1
F. Fence Bracket Assembly ............................ 1
G. Fence Sliding Handle ................................. 1
H. Locking Plate Assembly ............................. 1
I. Fence Support ............................................ 1
J. Dust Chute ................................................. 1
K. Dust Collection Bag Clamp ........................ 1
Hardware (Not Shown) ................................. Qty
• Cap Screws M8-1.25 x 20 .......................... 6
• Lock Washers 8mm.................................... 6
• Hex Wrench 4mm ....................................... 1
• Hex Wrench 6mm ....................................... 1
Figure 4
.
Large components.
A
B
Figure 5
.
Small components.
C
D
F
E
G
K
H
J
I
To Next Page
