Model G0725 (Mfd. Since 03/18)
-3-
Identification
Figure 1. G0725 identification — front view.
Figure 2. G0725 identification — back view.
A. Outfeed Table
B. Fence
C. Infeed Table
D. Push Blocks
E. Depth of Cut Adjusting Knob
F. ON/OFF Switch w/ Disabling Key
G. Cutterhead Guard
H. Dust Collection Bag
I. Fence Bracket Assembly
J. Fence Tilting Handle
K. Fence Sliding Handle
D
I
A
B
C
E
D
G
H
K
J
F
To reduce the risk of
serious injury when using
this machine, read and
understand this entire
manual before beginning
any operations.
For Your Own Safety, Read Instruction
Manual Before Operating Jointer
a) Wear eye protection.
b) Always keep cutterhead and drive guards
in place and proper operating condition.
c) Always use hold down/push blocks
for jointing material narrower than 3
inches, or planing material thinner than 3
inches.
d) Never perform jointing or planing on
pieces shorter than 8 inches.
To Next Page
