-52-
Model G0803Z (Mfd. Since 12/18)
Main Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
1 P0803Z001 KNOB BOLT M6-1 X 20, D21, TAPERED KN 50 P0803Z050 PHLP HD SCR M5-.8 X 10
2 P0803Z002 FLAT WASHER 6MM 51 P0803Z051 FLAT HD SCR M3-.5 X 4
3 P0803Z003 MITER GAUGE BODY W/SCALE 52 P0803Z052 DUST PORT 2"
4 P0803Z004 PHLP HD SCR M4-.7 X 6 53 P0803Z053 FOAM GASKET 8 X 5 X 120
5 P0803Z005 FLAT WASHER 4MM 54 P0803Z054 FRAME
6 P0803Z006 MITER GAUGE SCALE POINTER 55 P0803Z055 HEX BOLT M6-1 X 16
7 P0803Z007 MITER BAR 56 P0803Z056 WHEEL SHAFT (LOWER)
8 P0803Z008 TABLE INSERT 57 P0803Z057 TIMING BELT PULLEY (WHEEL)
9 P0803Z009 TABLE 58 P0803Z058 BALL BEARING 6000-2RS
10 P0803Z010 "D" NUT M6-1 59 P0803Z059 TIMING BELT PULLEY (MOTOR)
11 P0803Z011 FLAT WASHER 6MM 60 P0803Z060 FENDER WASHER 5MM
12 P0803Z012 LOCK WASHER 6MM 61 P0803Z061 CAP SCREW M5-.8 X 10
13 P0803Z013 WING BOLT M6-1 X 16 62 P0803Z062 SWITCH MOUNTING PLATE
14 P0803Z014 HEX NUT M10-1.5 63 P0803Z063 GRIZZLY PADDLE SWITCH
15 P0803Z015 PUSH STICK 64 P0803Z064 WHEEL (LOWER)
16 P0803Z016 PHLP HD SCR M5-.8 X 12 65 P0803Z065 PHLP HD SCR M5-.8 X 16
17 P0803Z017 LOCK WASHER 5MM 66 P0803Z066 CAP SCREW M5-.8 X 10
18 P0803Z018 FLAT WASHER 5MM 67 P0803Z067 EXT RETAINING RING 10MM
19 P0803Z019 PUSH STICK HOLDER 68 P0803Z068 TIMING BELT 130XL 10
20 P0803Z020 HEX NUT M6-1 69 P0803Z069 RUBBER FOOT
21 P0803Z021 CAP SCREW M6-1 X 24 70 P0803Z070 SCALE
22 P0803Z022 ADJUSTABLE HANDLE 60L, M8-1.25 X 25 71 P0803Z071 FENCE RAIL CAP (LEFT)
23 P0803Z023 FENDER WASHER 8MM 72 P0803Z072 FENCE RAIL CAP (RIGHT)
24 P0803Z024 CAP SCREW M6-1 X 14 73 P0803Z073 FENCE RAIL
25 P0803Z025 TRUNNION W/SCALE 74 P0803Z074 WORKLAMP W/SWITCH, LED BULB 12V, 1W
26 P0803Z026 STANDOFF-ROUND FF M6-1 X 14 75 P0803Z075 QUICK-RELEASE LEVER 8 X 95
27 P0803Z027 SHOULDER SCREW M5-.8 X 10, 8 X 35 76 P0803Z076 SET SCREW M5-.8 X 6
28 P0803Z028 COMPRESSION SPRING 0.8 X 10 X 25 77 P0803Z077 QUICK-RELEASE ECCENTRIC SHAFT
29 P0803Z029 GEARED KNOB 8 X 39, D46, 12T 78 P0803Z078 WAVY WASHER 16 X 21 X 0.3MM
30 P0803Z030 PHLP HD SCR M5-.8 X 8 79 P0803Z079 QUICK-RELEASE MOUNT BRACKET
31 P0803Z031 TABLE TILT SCALE POINTER 80 P0803Z080 QUICK-RELEASE ECCENTRIC BUSHING
32 P0803Z032 FLAT WASHER 8MM 81 P0803Z081 KNOB BOLT M8-1.25 X 35, D32, 6-LOBE
33 P0803Z033 CAP SCREW M8-1.25 X 14 82 P0803Z082 DOOR LOCK CAM KNOB 40D
34 P0803Z034 LED TRANSFORMER 83 P0803Z083 SHOULDER SCREW M5-.8 X 6, 8 X 12
35 P0803Z035 PHLP HD SCR M5-.8 X 8 84 P0803Z084 RUBBER TUBE 8 X 40
36 P0803Z036 LOCK WASHER 5MM 85 P0803Z085 CAP SCREW M5-.8 X 16
37 P0803Z037 EXT TOOTH WASHER 5MM 86 P0803Z086 CARRYING HANDLE
38 P0803Z038 CAP SCREW M8-1.25 X 20 87 P0803Z087 LOC-LINE 1/2 NPT, 15"
39 P0803Z039 MOTOR 1/3HP 120V 1-PH 88 P0803Z088 HEX NUT M12-1.25 THIN BRASS
39-1 P0803Z039-1 MOTOR FAN COVER 89 P0803Z089 KNOB W/SHAFT 6 X 22, D32, 6-LOBE
39-2 P0803Z039-2 MOTOR FAN 90 P0803Z090 WAVY WASHER 6MM
39-3 P0803Z039-3 CAPACITOR COVER 91 P0803Z091 SET SCREW M4-.7 X 4
39-4 P0803Z039-4 R CAPACITOR 20M 250-350V 1-3/8 X 2-3/8 92 P0803Z092 ADJUSTMENT KNOB SEAT
39-5 P0803Z039-5 BALL BEARING 6201ZZ (REAR) 93 P0803Z093 GEAR 10T
39-6 P0803Z039-6 BALL BEARING 6202ZZ (FRONT) 94 P0803Z094 LOCK NUT M5-.8
40 P0803Z040 POWER CORD 18G 3W 72" 5-15P 95 P0803Z095 UPPER BLADE GUIDE BLOCK
41 P0803Z041 STRAIN RELIEF TYPE-1 1/2 96 P0803Z096 SQUARE NUT M8-1.25
42 P0803Z042 CHIP BLOWER MOTOR COVER 97 P0803Z097 CAP SCREW M6-1 X 8
43 P0803Z043 CHIP BLOWER MOTOR 3.5W 12V 98 P0803Z098 BLADE GUIDE LIMIT PLATE
44 P0803Z044 TAP SCREW M3 X 6 99 P0803Z099 FLAT HD SCR M4-.7 X 8
45 P0803Z045 CHIP BLOWER FAN 100 P0803Z100 BLADE COVER (LOWER)
46 P0803Z046 CHIP BLOWER FAN COVER 101 P0803Z101 CAP SCREW M5-.8 X 6
47 P0803Z047 KNOB BOLT M8-1.25 X 14, D32, 6-LOBE 102 P0803Z102 WHEEL BRUSH SEAT
48 P0803Z048 COMPRESSION SPRING 1 X 13 X 18 103 P0803Z103 WHEEL BRUSH
49 P0803Z049 FLAT WASHER 8MM 104 P0803Z104 BLADE GUIDE BLOCK (LOWER)
