Grizzly G9249 - Spindle Lever


 
Spindle Lever
("#
("$
("%
("&
("'
("(
(")
("*
("+
(#"
(##
(#$
(#%
(#&
REF PART # DESCRIPTION REF PART # DESCRIPTION
601 PRP14M ROLL PIN 3 X 6 608 P9249608 COMPRESSION SPRING 1 X 6 X 22
602 PK14M KEY 5 X 5 X 18 609 P9249609 COVER
603 P9249603 BUSHING 610 PRP45M ROLL PIN 5 X 32
604 P9249604 LEVER BRACKET 611 P9249279 STEEL BALL 6MM
605 PSB26M CAP SCREW M6-1 X 12 612 P9249612 COMPRESSION SPRING 1 X 6 X 9
606 P9249606 HANDLE 613 PSS16M SET SCREW M8-1.25 X 10
607 P9249607 KNOB M10 X 50 614 P9249614 TAPERED SET SCREW M8-1.25 X 12
