Model T31739 (Mfd. Since 11/19)
-13-
NOTICE
If you cannot find an item on this list, care-
fully check around/inside the machine and
packaging materials. Often, these items get
lost in packaging materials while unpack-
ing or they are pre-installed at the factory.
Inventory
The following is a list of items shipped with your
machine. Before beginning setup, lay these items
out and inventory them.
If any non-proprietary parts are missing (e.g. a
nut or a washer), we will gladly replace them; or
for the sake of expediency, replacements can be
obtained at your local hardware store.
Box 1 (Figure 5) Qty
A. Table Assembly .......................................... 1
B. Headstock Assembly .................................. 1
C. Downfeed Handles ..................................... 3
D. Speed Lever ............................................... 1
E. Column Assembly ...................................... 1
F. Chuck
1
⁄32"-
5
⁄8" JT3 Keyless ........................ 1
G. Chuck Arbor JT3 x MT2 ............................. 1
H. Table Lock Handles .................................... 2
I. Table Height Crank Handle ........................ 1
J. Drift Key ...................................................... 1
K. Hex Wrenches 3, 4, 5mm .....................1 Ea.
L. Hex Bolts M8-1.25 x 20 .............................. 4
M. Base ........................................................... 1
Figure 5. T31739 loose parts inventory.
A
B
C
D
E
F
G
H
I
J
K
L
M
