Model T31739 (Mfd. Since 11/19)
-3-
Identification
Become familiar with the names and locations of the controls and features shown below to better understand
the instructions in this manual.
Belt Cover
Motor
ON/OFF
Buttons
Laser & Light
Switches
Base
Table
Column
Chuck
Spindle
Adjustable
Depth Stop
Depth Stop
Scale
Emergency
Stop Button
Quill
Digital
Readout
Downfeed
Handle
Spindle
Return Spring
Rack
Workpiece
Support
Spindle Speed
Lever
Table Pivot
Lock Handle
Table Height
Lock Handle
Table Height
Crank Handle
For Your Own Safety Read Instruction Manual Before Operating Drill Press
a) Wear eye protection.
b) Do not wear gloves, necktie, or loose clothing.
c) Clamp workpiece or brace against column to prevent rotation.
d) Use recommended speed for drill accessory and workpiece material.
To Next Page
