2.1.1 Interface
The description of Shine WebBox Interface is listed below.
Label
Function
1
2
4
5
6
7
8
9
10
SWITCH
Power Port
LAN Port
COM Port
USB Port
SD-CARD
ANTENNA
NORMAL-LED
FAULT-LED
Name
Power Switch:Turn On/Off Shine WebBox
Power Line:Connect the power line to charge
RJ45 port:Connect Shine WebBox to the local
network area of Shine Server through web line
As to COM port, pin 2 and pin 4 are used for
RS485; Others for active and reactive power
adjustment
Auto-update via USB flash disk
Data storage via SD-CARD
Receive wireless signal
Green led, normal state
Red led, fault state.
2.1.2 Indicator Led
Indicator led can be divided into red led and green led.
Red led equals to fault-led, Green led equals to normal-led.
There are 6 different led color combinations which stand for different situations.
Red led
Description
Long lighting
Go out
Go out
Go out
Long lighting
Long lighting with
bumming
Long lighting
Flash slowly
Flash quickly
Long lighting
Go out
Go out
Green led
System starting
Searching inverters
Some inverter is standing by
Inverters work normally
No SD card inserted
Inverters report error
