Growatt SPH-UP Series User Manual

Index
1 Brief Introduction
2 Safety
3 Product Description
3.1 SPH series inverter
3.2 Label Explanation
3.3 Size and weight
3.4 The advantage of the unit of SPH
1.1 Preface
1.2 Target Group
1.3 Product Description
1.4 Safety Instructions
2.1 Purpose Use
2.2 Safety Measure
2.3 Symbols introduction on the SPH
inverter
4 Unpacking
5 Installation
5.1 Basic installation requirements
5.2 Installation requires tools and RJ45
terminal sequence of the LAN line
5.3 Installation Instructions
5.4 SPH System Connection Mode
6.1 Commissioning of SPH
6.2 Operation modes
6.3 Display and button
6.4 Communication
6.5 Country setting
6 Commissioning

Growatt SPH-UP Series Specifications

General

Type	Hybrid Inverter
Protection Rating	IP65
Number of MPPTs	2
AC Voltage Range	180-280V
THDi	<3%
AC Grid Frequency	50/60Hz
Communication Interfaces	Wi-Fi, RS485, USB
Nominal AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Cooling
