Growatt SPH-UP Series User Manual

11 Product specification
11.1 SPH series inverter machine product specification
SPH 3000TL
BL-UP
SPH 3600TL
BL-UP
SPH 4000TL
BL-UP
SPH 4600TL
BL-UP
SPH 5000TL
BL-UP
SPH 6000TL
BL-UP
Input data(DC)
Max.
recommended
PV power(for
module STC)
6500W
7500W
8500W
9000W
9500W
10600W
Max. DC voltage
550V
550V
550V
550V
550V
550V
Start voltage
120V
120V
120V
120V
120V
120V
Nominal voltage
370V
370V
370V
370V
370V
370V
MPP work
voltage range
120V-550V
120V-550V
120V-550V
120V-550V
120V-550V
120V-550V
Full load dc
voltage range
275V-440V
275V-440V
275V-440V
340V-440V
340V-440V
340V-440V
Number of
independent
MPP trackers
2
No. of PV strings
per MPP trackers
1
Max. input
current per MPP
trackers
13.5A
Max. short-
circuit current
per MPP trackers
20A
Backfeed current
to the array
0A
AC input / output data
Rated input /
output power
3000/3000
W
3680/3680
W
4000/4000
W
4600/4600
W
5000/5000
W
6000/6000
W
Rated output
apparent power
3000VA
3600VA
4000VA
4600VA
5000VA
6000VA
Nominal AC
voltage/range
230V ;
180Vac-
260Vac
230V ;
180Vac-
260Vac
230V ;
180Vac-
260Vac
230V ;
180Vac-
260Vac
230V;
180Vac-
260Vac
230V ;
180Vac-
260Vac
Nominal
Frequency
50Hz
50Hz
50Hz
50Hz
50Hz
50Hz
Rated input /
output current
13.5/ 13.5 A
16/16 A
17.5/17.5 A
20/20 A
22/22A
27/27 A
Max inrush peak
current
10A(5mS)
Model
Specifications
SPH 3000TL
BL-UP
SPH 3600TL
BL-UP
SPH 4000TL
BL-UP
SPH 4600TL
BL-UP
SPH 5000TL
BL-UP
SPH 6000TL
BL-UP
Maximum output
fault peak curren
65A(56uS)
Maximum output
over current
protection
65A
Phase factor at
rate power
1
Displacement
power factor,
configurable*
0.8leading…0.8lagging
THDI
<3%
AC connection
Single phase
Stand alone(AC power)
Growatt SPH
&SPH TL BL-UP
Rated output
apparent power
3000VA
3680VA
4000VA
4000VA
4000VA
4000VA
Nominal voltage
230V
Rated Frequency
AC output
50Hz
Rated output
current
13A
16A
17.5A
17.5A
17.5A
17.5A
THDv
3%
Switch time(SPH
TL BL-UP))
≤10ms
BAT data（DC）
Battery voltage
range
42~59V
Minimum full
load voltage
46V
48V
48V
48V
48V
48V
Rated charging
and discharging
current
66A
75A
85A
85A
85A
85A
Continuous
charging /
discharging
power
3000/300
0 W
3680/368
0 W
4000/400
*1
0 W
4000/400
*1
0 W
4000/400
*1
0 W
4000/400
*1
0 W
Type of Battery
ithium /Lead-acid
Efficiency
Max. efficiency
97.2%
97.2%
97.3%
97.4%
97.5%
97.6%
Model
Specifications
59
60

Growatt SPH-UP Series Specifications

General

Type	Hybrid Inverter
Protection Rating	IP65
Number of MPPTs	2
AC Voltage Range	180-280V
THDi	<3%
AC Grid Frequency	50/60Hz
Communication Interfaces	Wi-Fi, RS485, USB
Nominal AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Cooling
