Growatt SPH-UP Series User Manual

SPH 3000TL
BL-UP
SPH 3600TL
BL-UP
SPH 4000TL
BL-UP
SPH 4600TL
BL-UP
SPH 5000TL
BL-UP
SPH 6000TL
BL-UP
Euro weighted
efficiency
97%
97%
97.1%
97.1%
97.2%
97.2%
MPPT efficiency
≥99.5%
Protection devices
Safety level
Class II
Overvoltage
category
PV:II AC:III Others:I
Ingress
protection
IP65
Inverter topology
Non-isolated
Operating
temperature
range
–25°C ... +60°C (-13...+140℉) with derating above 45°C /113℉
Safety level
Class I
Ingress
protection
IP65
DC switch
*2
optional
DC reverse-
polarity
protection
Integrated
DC Surge
protection
Type II
Insulation
resistance
monitoring
Integrated
AC surge
protection
Type II
AC short-circuit
protection
Integrated
Ground fault
monitoring
Integrated
Grid monitoring
Integrated
Anti-islanding
protection
Integrated(Active Frequency Drift)
Residual-current
monitoring unit
Integrated
General Data
Dimensions (W /
H / D) in mm
565*456*188
Weight
27KG
Noise e m i s s i o n
(typical)
≤ 25 dB(A)
Altitude
2000m
Model
Specifications
SPH 3000TL
BL-UP
SPH 3600TL
BL-UP
SPH 4000TL
BL-UP
SPH 4600TL
BL-UP
SPH 5000TL
BL-UP
SPH 6000TL
BL-UP
Self-
Consumption
< 10 W
Cooling concept
Natural
Relative humidity
100%
Features
DC connection
MC4/H4(opt)
AC connection
connector
BAT connection
OT Terminal
Display
LCD
Interfaces:
RS485/ USB
/CAN
yes /yes /yes
Warranty: 5
years / 10 years
yes /opt
Certificates and
approvals
CE, IEC62109, G98/G99, VDE0126-1-1, AS4777, CEI 0-21, VDE-AR-
N4105, UTE C 15-712，EN50549, IEC 61727, IEC 62116, IEC 62040
,,C10/11,NRS 097-2-1
Model
Specifications
Note:
*1
1. Continuous charging current: if there is PV and the PV power is large enough, the
maximum continuous charging power can reach 4000W; If there is no PV, only AC is
connected, the maximum continuous charging power is 3000W.
*2
2. in built DC switch isolator is optional in Australia for SPH .
11.2 DC input terminal parameter
2
2.5mm /14AWG
2
4mm /12 AWG
2
6mm /10 AWG
2
10mm /8AWG
DC connection
MC4
MC4
Mc4
MC4
Rated current
(90℃
environment)
32A
40A
44A
65A
Nominal system
voltage
600V DC(UL)
600V DC(TUV)
Contact
resistance
0.25mΩ（model）
Protection grade
IP68
MC4 specification:
61 62

Growatt SPH-UP Series Specifications

General

Type	Hybrid Inverter
Protection Rating	IP65
Number of MPPTs	2
AC Voltage Range	180-280V
THDi	<3%
AC Grid Frequency	50/60Hz
Communication Interfaces	Wi-Fi, RS485, USB
Nominal AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Cooling
