Growatt SPH-UP Series User Manual

Hybrid Inverter
Model name
SPH 6000TL BL-UP
PV input data
Max. PV voltage
550V d.c.V
PV voltage range
120-550 d.c.V
PV Isc
20 d.c.A*2
Max.input current
13.5 d.c.A*2
AC output/input data
Rated output/input power
6000/6000W
Rated output apparent power
6000VA
Nominal voltage
230 a.c.V
Rated input / output current
27/27 a.c.A
Nominal Frequency
50Hz
Power factor range
0.8leading～0.8lagging
EPS output data
Rated output apparent power
4000VA
Rated voltage
230 a.c.V
Rated output current
17.5 a.c.A
Nominal Frequency
50 Hz
Power factor range
0.8leading～0.8lagging
Battery data
Battery voltage range
42～59 d.c.V
Rated charging and discharging current
85 d.c.A
Type of Battery
Lithium/Lead-acid
Others
Safety level
Class I
Overvoltage category
PV:II AC:III Others: I
Ingress protection
IP65
Operation Ambient Temperature
-25℃～+60℃
Inverter topology
Non-isolated
Certificate No
SAA211107
Description of label:
10
9
3.3 Size and weight
3.4 The advantage of the unit of SPH
Features below:
·All of the designs are designed to enhance the self-use function of photovoltaic energy.
·Smart management, work mode can be set
·Safe battery used
·Easy installation
·Two MPP tracker input
·The switching time between off-grid and grid-connected is less than 10mS
·With multi-machine anti - current parallel function
Chart 3.1
A(mm)
B(mm)
C(mm)
weight(kg)
SPH TL BL-UP
456
565
188
27

Growatt SPH-UP Series Specifications

General

Type	Hybrid Inverter
Protection Rating	IP65
Number of MPPTs	2
AC Voltage Range	180-280V
THDi	<3%
AC Grid Frequency	50/60Hz
Communication Interfaces	Wi-Fi, RS485, USB
Nominal AC Voltage	230 V
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Cooling
