Growatt SPH6000 User Manual

Maximum output
fault peak current
65A(56uS)
Maximum output
over current
protection
65A
Phase factor at
rate power
1
Displacement
power factor,
configurable*
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…
0.8lagging
0.8leading…0.
8lagging
THDI <3% <3% <3% <3% <3% <3%
AC connection Single phase Single phase Single phase Single phase Single phase Single phase
EPS output data(AC power)
Growatt SPH
&SPH TL BL-
UP
Rated output
apparent power
3000VA&30
00VA
3000VA&368
0VA
3000VA&400
0VA
3000VA&400
0VA
3000VA&400
0VA
3000VA&4000
VA
Nominal voltage 230V 230V 230V 230V 230V 230V
Rated Frequency
AC output
50 Hz 50 Hz 50 Hz 50 Hz 50 Hz 50 Hz
Growatt SPH
&SPH TL BL-UP
Rated output
current
13A/13A 13A/16A 13A/17.5A 13A/17.5 13A/17.5A 13A/17.5A
THDv 3% 3% 3% 3% 3% 3%
Switch time
(SPH
TL BL-UP))
≤10ms ≤10ms ≤10ms ≤10ms ≤10ms ≤10ms
BAT data（DC）
Battery voltage
range
42~59V 42~59V 42~59V 42~59V 42~59V 42~59V
Minimum full
load voltage
46V 48V 48V 48V 48V 48V
Growatt
SPH&SPH TL
BL-UP Rated
charging and
discharging
current
66A& 66A 66A&75A 66A&85A 66A&85A 66A&85A 66A&85A
Growatt
SPH&SPH TL
BL-UP
Continuous
charging /
3000W&300
0W
3000W&368
0 W
*1
3000W&400
0 W
*1
3000W&400
0 W
*1
3000W&400
0 W
*1
3000W&4000
W
*1

Growatt SPH6000 Specifications

General

Model	SPH6000
Category	Inverter
Rated Power	6000 W
Max. DC Voltage	550 V
Max. Output Current	27.3 A
Start Voltage	150 V
Nominal DC Voltage	360V
Number of DC Inputs	2
Number of MPP Trackers	2
Nominal AC Power	6000 W
Max. AC Power	6600 W
Nominal Grid Frequency	50 Hz / 60 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Max. Output Power	6600 W
Output Voltage	230V
Output Frequency	50/60 Hz
Nominal AC Voltage	230V
AC Voltage Range	180V-280V
Power Factor	0.8 leading - 0.8 lagging
Communication	RS485
Cooling Method	Natural Convection
