EINSTELLUNGEN
Status-Symbole am unteren Bildschirmrand
1
Betriebsart
= Automatische Nachtabsenkung
= Ändern von Einstellungen ist gesperrt
= An Feldbus angeschlossen
= Mehrpumpenanlage
= Master-Pumpe (Mehrpumpenanlage)
= Slave-Pumpe (Mehrpumpenanlage)
= Vor-Ort-Betriebsmodus (Feldbus wird übersteuert)
Normal
Stopp
Min.
Max.
Die Pumpe läuft entsprechend der ausgewählten
Regelungsart. Die Betriebsart übersteuert die
Regelungsart.
Siehe nächste Seite
Die Pumpe wird gestoppt.
Die MIN-Kennlinie wird in Zeiten mit
minimalem Förderstrombedarf verwendet.
Die MAX-Kennlinie wird in Zeiten
mit maximalem Förderstrombedarf
verwendet.
Regelungsart
2
AUTOADAPT
Proportionaldruck
Konstantdruck
FLOWADAPT
Konstanttemperatur
Dierenztemperatur
Konstanter Durchuss
Konstantkennlinie
Δt
Δt
Δt
Δt
1
Δt
Δt
Δt
Die Betriebsart kann extern über einen Digitaleingang gesteuert werden.
