The device controls
The front of the device
Jog-Shuttle Rotate the Jog-Shuttle to set
and to confirm the preferred
options.
Press to activate and confirm
the functions and the menus.
For more details, please see
“Jog-Shuttle” section.
_
+ Turn left or right to select
menu options or to adjust the
volume.
Press for confirming the
selected option.
Display of the device, for
more details, please see “The
device displays” section.
Infrared sensor for remote
control signals.
iPod dock Press to open the iPod dock,
drawer and to connect the iPod/
iPhone.
_
LCD Display
IR sensor
Jog-Shuttle
+
iPod dock drawer
