z Please install surge absorbing elements in sensible elements (loop) in related
circuits: DC loop is reversely connected in parallel with continuous current diode
while AC loop is connected in parallel with capacitance-resistance absorbing return
circuit.
Attention
U, V and W shall be connected with motor winding in the way of one-to-one correspondence. Revers
connecting shall be forbidden.
The wires and leads shall be fastened firmly and avoid approaching radiator of the drive unit and th
motor for the fear that the insulation performance will be reduced due to heat.
There will remain large quantities of electrolyzed capacitance in the servo drive unit, so there will
high remaining voltage even after the power is cut off. Do not touch drive unit or motor within
minutes after the power is off!
