DA98D User Manual
59
8.3 Isolating Transformer
z It is recommended that the power of drive unit is supplied by isolating transformer for
reducing the possibility of electric shock and jamming by power supply and electromagnetic
field.
z Drive units of 0.8kW and below can adopt single-phase power supply while drive units of
more than 0.8kW can adopt three-phase power supply.
We provide the following several models of transformers for the user to select. The user can
make a choice by referring to the power and actual load of servo motor.
Table 8.5 Specifications on Some Isolating Transformers
Models Capacity (kVA)
Phase
Number
Input Voltage (V)
Output Voltage
(V)
BS—120 1.2
BS—200 2.0
BS—300 3.0
Three
BD—80 0.8
BD—120 1.2
Single
380 220
Attention
